Imou Ranger Mini Specifications
| Specification | Details |
|---|---|
| Brand | Imou |
| Model | Ranger Mini |
| Camera Type | Indoor Pan & Tilt Wi-Fi Camera |
| Image Sensor | 1/3″ Progressive CMOS |
| Effective Pixels | 3MP |
| Resolution | 2304 × 1296 |
| Frame Rate | Up to 20fps |
| Lens | 3.6mm Fixed |
| Pan | 355° |
| Tilt | -5° to 50° |
| Digital Zoom | 8× |
| IR Night Vision | Up to 10m |
| Audio | Two-Way Audio |
| Microphone | Built-in |
| Speaker | Built-in |
| Detection | Motion & Human Detection |
| Storage | MicroSD up to 512GB |
| Wi-Fi | IEEE 802.11b/g/n/ax |
| Wi-Fi 6 | Yes |
| Ethernet | 1 × 100Mbps |
| App | Imou App |
| Power | DC 5V/1A |
| Power Consumption | <4.2W |
| USB | USB-C |
| Color | White |
| Dimensions | 95 × 96 × 109.2mm |
| Weight | 200g |
| Operating Temperature | -10°C to +45°C |
| Warranty | 1 Years |
Imou Ranger Mini 3MP 2K Pan & Tilt Wi-Fi Camera
The Imou Ranger Mini is a compact 3MP 2K Pan & Tilt Portable Wi-Fi Camera designed for indoor home, office and small-business monitoring. It combines clear 2304×1296 video resolution with remote pan and tilt control, smart detection, night vision and two-way audio.
With its compact design, the camera can be placed on a table or installed using its integrated mounting design. It is suitable for users who want flexible indoor monitoring without a complicated installation setup.
Key Features of Imou Ranger Mini
- 3MP Progressive CMOS image sensor
- 2K resolution up to 2304×1296
- Up to 20fps frame rate
- 3.6mm fixed lens
- 355° pan
- -5° to 50° tilt
- 8× digital zoom
- Up to 10m IR night vision
- Smart full-color night vision
- Human detection
- Motion detection
- Abnormal sound alarm
- Two-way audio
- Built-in microphone and speaker
- MicroSD card support up to 512GB
- Wi-Fi 6 support
- 100Mbps Ethernet port
- Imou App support
- USB-C connection
- Compact portable design
3MP 2K High-Resolution Monitoring
The Imou Ranger Mini uses a 3MP 1/3-inch Progressive CMOS sensor and provides a maximum resolution of 2304 × 1296 pixels.
This 2K resolution provides more image detail than standard Full HD, making it useful for monitoring rooms, entrances, offices, shops and other indoor areas. The camera supports video at up to 20fps according to the current Bangladesh specification.
355° Pan & -5° to 50° Tilt
One of the main advantages of the Imou Ranger Mini is its remotely controllable pan and tilt mechanism.
It supports up to 355° horizontal pan and -5° to 50° vertical tilt, allowing users to adjust the viewing direction through the camera system and cover a wide indoor area.
Smart Night Vision
The camera supports night vision with an IR distance of up to 10 meters.
It also supports smart full-color night vision. Depending on the selected mode and conditions, the camera can provide infrared or full-color monitoring for improved visibility at night.
Human Detection and Smart Alerts
The Imou Ranger Mini supports smart detection features including:
- Human Detection
- Motion Detection
- Configurable Region
- Abnormal Sound Alarm
These features can help users monitor activity and receive relevant alerts instead of relying only on continuous manual monitoring.
Two-Way Audio
The built-in microphone and speaker provide two-way audio communication.
Users can communicate through the camera using the Imou mobile application, making the camera useful for home monitoring, office communication and checking on people or activities remotely.
8× Digital Zoom
The Imou Ranger Mini supports up to 8× digital zoom, allowing users to digitally enlarge portions of the live or recorded view when additional detail is required.
Flexible Storage Options
The camera includes a MicroSD card slot supporting up to 512GB according to the current Bangladesh listing.
This provides a convenient local storage option for users who want to record and review camera footage. Actual recording duration depends on resolution, recording mode, activity and memory-card capacity.
Wi-Fi 6 and Ethernet Connectivity
The Imou Ranger Mini supports IEEE 802.11b/g/n/ax Wi-Fi, including Wi-Fi 6 connectivity.
It also provides 1 × 100Mbps Ethernet port, giving users the option of a wired network connection where required.
Suitable For
The Imou Ranger Mini is suitable for:
- Home security monitoring
- Office monitoring
- Shop monitoring
- Baby/child monitoring
- Elderly monitoring
- Indoor surveillance
- Small business monitoring
- Room monitoring
- Remote viewing
- Two-way communication
10. Why Choose Imou Ranger Mini?
The Imou Ranger Mini combines 3MP 2K video, remote pan & tilt, smart detection, night vision, two-way audio and flexible storage in a compact design.
Its Wi-Fi 6 and Ethernet connectivity provide flexible installation options, while the Imou App allows convenient remote access and management.
FAQ
Is Imou Ranger Mini a 3MP camera?
Yes. The Ranger Mini uses a 3MP sensor and supports up to 2304×1296 resolution.
Does Imou Ranger Mini support pan and tilt?
Yes. It supports 355° pan and -5° to 50° tilt.
What is the night vision range?
The current specification lists up to 10 meters IR night vision.
Does it support human detection?
Yes. Human detection and motion detection are supported.
Does Imou Ranger Mini have two-way audio?
Yes. It has a built-in microphone and speaker for two-way audio communication.
What is the maximum MicroSD capacity?
The current Bangladesh listing specifies support for up to 512GB MicroSD.
Does it support Wi-Fi 6?
Yes. The listed wireless standard includes 802.11ax, which is Wi-Fi 6
