Hikvision DS-2CE76G0T-LPFS/S Camera Full Specifications

Hikvision DS-2CE76G0T-LPFS/S Camera

Hikvision DS-2CE76G0T-LPFS/S Camera is a 3MP 2K dual-light audio fixed dome CCTV camera designed for reliable security monitoring in homes, offices, shops, warehouses and commercial environments. It combines a 2K CMOS image sensor, dual-light illumination, built-in microphone and flexible 4-in-1 video output in a compact dome-style body. The camera supports TVI, AHD, CVI and CVBS video formats, making it compatible with a wide range of compatible DVR systems.

3MP 2K High-Quality Imaging

The Hikvision DS-2CE76G0T-LPFS/S Camera features a 2K CMOS image sensor with a maximum resolution of 2304 × 1296. This provides more image detail than a standard 1080p camera and can help users monitor important areas with clearer video.

The camera supports 2K resolution at up to 20fps through TVI, while 1080p video can be transmitted at 25fps or 30fps depending on the selected video standard. AHD and CVI modes also support 1080p at 25fps/30fps.

Dual Light Technology

A major feature of the Hikvision DS-2CE76G0T-LPFS/S Camera is its Smart Hybrid Light or dual-light capability. The camera combines infrared and white-light illumination to provide better visibility during nighttime or low-light conditions.

It offers up to 20 meters of IR illumination and up to 20 meters of white-light illumination. The available Smart, IR and White Light modes allow the camera to adapt its supplementary lighting according to the surveillance environment.

This makes the camera suitable for entrances, shops, corridors, offices, residential areas and other locations that require dependable night monitoring.

Built-in Microphone and Audio over Coaxial

The Hikvision DS-2CE76G0T-LPFS/S Camera includes a built-in microphone and supports audio transmission over the coaxial cable. This means compatible DVR systems can receive video and audio through the same coaxial connection, reducing the need for a separate audio cable in supported installations.

Audio capability can be useful for monitoring areas such as reception desks, shop counters, entrances and office spaces where sound can provide additional context to recorded video.

2.8mm and 3.6mm Fixed Lens Options

The camera is available with 2.8mm and 3.6mm fixed focal lens options. The 2.8mm lens provides a wider field of view, with approximately 105° horizontal, 60° vertical and 129° diagonal viewing angles.

The 3.6mm option provides approximately 89° horizontal, 47° vertical and 107° diagonal field of view. Users can select the appropriate lens option according to the required surveillance area.

4-in-1 Video Compatibility

The Hikvision DS-2CE76G0T-LPFS/S Camera supports switchable TVI, AHD, CVI and CVBS video output. This 4-in-1 compatibility makes it easier to integrate the camera with compatible DVR systems using different HD analog technologies.

For customers upgrading an existing CCTV installation, this flexibility can be particularly useful because the camera can be configured according to the supported signal type of the DVR.

Clear Images in Different Lighting Conditions

The camera supports Digital WDR along with DWDR, BLC, HLC and global image enhancement functions. These technologies help improve image visibility when the scene contains challenging lighting conditions.

The camera also uses ICR day/night switching and supports a minimum illumination level of 0.01 Lux under specified conditions, while IR illumination enables visibility in very low-light environments.

Flexible Installation and Compact Design

The Hikvision DS-2CE76G0T-LPFS/S Camera has a compact body measuring approximately 84.6mm × Ø85.02mm and weighs around 155 grams. Its adjustment range includes 0–360° pan, 0–75° tilt and 0–360° rotation, allowing installers to position the camera according to the required monitoring area.

The camera operates from a 12V DC power supply and has a maximum power consumption of approximately 3.3W.

Suitable for Home, Office and Commercial Security

The Hikvision DS-2CE76G0T-LPFS/S Camera is suitable for a variety of CCTV applications. It can be used in homes, retail shops, offices, small businesses, warehouses, reception areas, corridors and other locations requiring fixed dome surveillance.

Its combination of 3MP 2K imaging, dual-light technology, built-in microphone and 4-in-1 video compatibility makes it a practical choice for customers who want both video and audio monitoring.

Hikvision DS-2CE76G0T-LPFS/S Camera Price in Bangladesh

The Hikvision DS-2CE76G0T-LPFS/S Camera price in Bangladesh varies depending on the seller, stock availability and warranty. Current Bangladesh listings show prices around ৳1,800 to ৳2,048, with Star Tech listing the camera at ৳2,048 and Techland BD listing it around ৳1,990 at the time of checking.

Before purchasing, customers should confirm the latest price, lens option, warranty and availability from Techno Hub Solution BD.

Why Choose Hikvision DS-2CE76G0T-LPFS/S Camera?

The Hikvision DS-2CE76G0T-LPFS/S Camera offers a strong combination of 3MP 2K imaging, Smart Hybrid Light, 20m IR and white-light illumination, built-in microphone, audio over coaxial and switchable TVI/AHD/CVI/CVBS output.

For users looking for an affordable Hikvision dome CCTV camera with audio and dual-light functionality, this model is a practical option for home, office, shop and commercial surveillance applications.

FAQ

What is Hikvision DS-2CE76G0T-LPFS/S?

Hikvision DS-2CE76G0T-LPFS/S is a 3MP 2K dual-light audio fixed dome CCTV camera with built-in microphone and switchable TVI/AHD/CVI/CVBS output.

What is the resolution of Hikvision DS-2CE76G0T-LPFS/S?

It provides a maximum resolution of 2304 × 1296, commonly described as 3MP/2K.

Does this Hikvision camera have a microphone?

Yes. The camera has a built-in microphone and supports audio transmission over coaxial cable.

What is the night vision range?

The camera provides up to 20 meters IR distance and up to 20 meters white-light distance.

Which lens is available?

It uses a fixed focal lens available in 2.8mm and 3.6mm options.

Does it support TVI, AHD and CVI?

Yes. Its video output can be switched between TVI, AHD, CVI and CVBS.

What is the price of Hikvision DS-2CE76G0T-LPFS/S in Bangladesh?

Current Bangladesh listings checked range approximately from ৳2,000 to ৳2,200, depending on seller and offer.
